The idea of programmability is the basis for the most precise definition of what SDN is: technology that separates the control plane management of network devices from the underlying data plane that forwards network traffic.

IDC broadens that definition of SDN by stating: “Datacenter SDN architectures feature software-defined overlays or controllers that are abstracted from the underlying network hardware, offering intent-or policy-based management of the network as a whole. This results in a datacenter network that is better aligned with the needs of application workloads through automated (thereby faster) provisioning, programmatic network management, pervasive application-oriented visibility, and where needed, direct integration with cloud orchestration platforms.”

The driving ideas behind the development of SDN are myriad. For example, it promises to reduce the complexity of statically defined networks; make automating network functions much easier; and allow for simpler provisioning and management of networked resources, everywhere from the data center to the campus or wide area network.

Separating the control and data planes is the most common way to think of what SDN is, but it is much more than that, said Mike Capuano, chief marketing officer for Pluribus.

“At its heart SDN has a centralized or distributed intelligent entity that has an entire view of the network, that can make routing and switching decisions based on that view,” Capuano said. “Typically, network routers and switches only know about their neighboring network gear. But with a properly configured SDN environment, that central entity can control everything, from easily changing policies to simplifying configuration and automation across the enterprise.”


How does SDN support edge computing, IoT and remote access?

A variety of networking trends have played into the central idea of SDN. Distributing computing power to remote sites, moving data center functions to the edge, adopting cloud computing, and supporting Internet of Things environments – each of these efforts can be made easier and more cost efficient via a properly configured SDN environment.

Typically in an SDN environment, customers can see all of their devices and TCP flows, which means they can slice up the network from the data or management plane to support a variety of applications and configurations, Capuano said. So users can more easily segment an IoT application from the production world if they want, for example.

Some SDN controllers have the smarts to see that the network is getting congested and, in response, pump up bandwidth or processing to make sure remote and edge components don’t suffer latency.

SDN technologies also help in distributed locations that have few IT personnel on site, such as an enterprise branch office or service provider central office, said Michael Bushong, vice president of enterprise and cloud marketing at Juniper Networks.

“Naturally these places require remote and centralized delivery of connectivity, visibility and security. SDN solutions that centralize and abstract control and automate workflows across many places in the network, and their devices, improve operational reliability, speed and experience,” Bushong said.

How does SDN support intent-based networking?

Intent-based networking (IBN) has a variety of components, but basically is about giving network administrators the ability to define what they want the network to do, and having an automated network management platform create the desired state and enforce policies to ensure what the business wants happens.

“If a key tenet of SDN is abstracted control over a fleet of infrastructure, then the provisioning paradigm and dynamic control to regulate infrastructure state is necessarily higher level,” Bushong said. “Policy is closer to declarative intent, moving away from the minutia of individual device details and imperative and reactive commands.”

IDC says that intent-based networking “represents an evolution of SDN to achieve even greater degrees of operational simplicity, automated intelligence, and closed-loop functionality.”

For that reason, IBN represents a notable milestone on the journey toward autonomous infrastructure that includes a self-driving network, which will function much like the self-driving car, producing desired outcomes based on what network operators and their organizations wish to accomplish, Casemore stated.

“While the self-driving car has been designed to deliver passengers safely to their destination with minimal human intervention, the self-driving network, as part of autonomous datacenter infrastructure, eventually will achieve similar outcomes in areas such as network provisioning, management, and troubleshooting — delivering applications and data, dynamically creating and altering network paths, and providing security enforcement with minimal need for operator intervention,” Casemore stated.

While IBN technologies are relatively young, Gartner says by 2020, more than 1,000 large enterprises will use intent-based networking systems in production, up from less than 15 in the second quarter of 2018.

How does SDN help customers with security?

SDN enables a variety of security benefits. A customer can split up a network connection between an end user and the data center and have different security settings for the various types of network traffic. A network could have one public-facing, low security network that does not touch any sensitive information. Another segment could have much more fine-grained remote access control with software-based firewall and encryption policies on it, which allow sensitive data to traverse over it.

“For example, if a customer has an IoT group it doesn’t feel is all that mature with regards to security, via the SDN controller you can segment that group off away from the critical high-value corporate traffic,” Capuano stated. “SDN users can roll out security policies across the network from the data center to the edge and if you do all of this on top of white boxes, deployments can be 30 – 60 percent cheaper than traditional gear.”

The ability to look at a set of workloads and see if they match a given security policy is a key benefit of SDN, especially as data is distributed, said Thomas Scheibe, vice president of product management for Cisco’s Nexus and ACI product lines.

“The ability to deploy a whitelist security model like we do with ACI [Application Centric Infrastructure] that lets only specific entities access explicit resources across your network fabric is another key security element SDN enables,” Scheibe said.

A growing number of SDN platforms now support microsegmentation, according to Casemore.

“In fact, micro-segmentation has developed as a notable use case for SDN. As SDN platforms are extended to support multicloud environments, they will be used to mitigate the inherent complexity of establishing and maintaining consistent network and security policies across hybrid IT landscapes,” Casemore said.

What is SDN’s role in cloud computing?

SDN’s role in the move toward private cloud and hybrid cloud adoption seems a natural. In fact, big SDN players such as Cisco, Juniper and VMware have all made moves to tie together enterprise data center and cloud worlds.

Cisco’s ACI Anywhere package would, for example, let policies configured through Cisco’s SDN APIC (Application Policy Infrastructure Controller) use native APIs offered by a public-cloud provider to orchestrate changes within both the private and public cloud environments, Cisco said.

“As organizations look to scale their hybrid cloud environments, it will be critical to leverage solutions that help improve productivity and processes,” said Bob Laliberte, a senior analyst with Enterprise Strategy Group, in a recent Network World article. “The ability to leverage the same solution, like Cisco’s ACI, in your own private-cloud environment as well as across multiple public clouds will enable organizations to successfully scale their cloud environments.”

Growth of public and private clouds and enterprises’ embrace of distributed multicloud application environments will have an ongoing and significant impact on data center SDN, representing both a challenge and an opportunity for vendors, said IDC’s Casemore.

“Agility is a key attribute of digital transformation, and enterprises will adopt architectures, infrastructures, and technologies that provide for agile deployment, provisioning, and ongoing operational management. In a datacenter networking context, the imperative of digital transformation drives adoption of extensive network automation, including SDN,” Casemore said.

Where does SD-WAN fit in?

The software-defined wide area network (SD-WAN) is a natural application of SDN that extends the technology over a WAN. While the SDN architecture is typically the underpinning in a data center or campus, SD-WAN takes it a step further.

At its most basic, SD-WAN lets companies aggregate a variety of network connections – including MPLS, 4G LTE and DSL – into a branch or network edge location and have a software management platform that can turn up new sites, prioritize traffic and set security policies.

SD-WAN’s driving principle is to simplify the way big companies turn up new links to branch offices, better manage the way those links are utilized – for data, voice or video – and potentially save money in the process.

SD-WAN lets networks route traffic based on centrally managed roles and rules, no matter what the entry and exit points of the traffic are, and with full security. For example, if a user in a branch office is working in Office365, SD-WAN can route their traffic directly to the closest cloud data center for that app, improving network responsiveness for the user and lowering bandwidth costs for the business.

“SD-WAN has been a promised technology for years, but in 2019 it will be a major driver in how networks are built and re-built,” Anand Oswal, senior vice president of engineering in Cisco’s Enterprise Networking Business, said a Network World article earlier this year.

It’s a profoundly hot market with tons of players including Cisco, VMware, Silver Peak, Riverbed, Aryaka, Fortinet, Nokia and Versa.

IDC says the SD-WAN infrastructure market will hit $4.5 billion by 2022, growing at a more than 40% yearly clip between now and then.
